Product Details
Stable and Reliable AED (Automatic Exposure Detection)
AnytimeTM
Vieworks’ proprietary AED function with reliable performance
Wireless Data Transmission
InsideAPTM
Fast wireless communication with IEEE 802.11n
Convenient Usability
High mobility with light and slim design
Easy upgrade: same size as a film or a CR cassette(ISO 4090)
Supreme Image Quality
High DQE & MT
Applications
General Radiography, ENT, Dental X-ray systems
Product Specifications
Model Name | FXRD-1012NA / FXRD-1012NB FXRD-1012NAW / FXRD-1012NBW |
Scintillator | CsI / Gadox |
Pixel Pitch | 124 ㎛ |
Pixel Matrix | 2048 x 2560 pixels |
Image Size | 10" x 12" (25.4 ㎝ x 31.7 ㎝) |
Grayscale | 16 bits |
Image Acquisition Time | Wired : 1.5 s Wireless: 3 s |
Dimensions | 28.7 ㎝ x 35.0 ㎝ x 1.5 ㎝ |
Weight | Wired : 2.0 kg Wireless: 2.2 kg(including battery) |
Battery | Litdium Ion 3100 mAh 3 h(capturing) |
Technology | a-Si TFT |
Spatial Resolution | 4.0 lp/㎜ |
Recommended Cycle Time | 15 s |
Data Interface | Gigabit Etdernet IEEE 802.11n |
X-ray Generator Interface | DR Trigger Mode / AED Mode |
Dust and Water Resistant | IP53 |
X-ray Voltage Range | 40 - 150 kVp |
Operating Environment | 10℃ to 35℃ 30 % to 85 % RH(non-condensing) |
Power Consumption | DC 24 V, 0.8 A |
* Specifications are subject to change witdout prior notice.
Model Name | FXRD-1012NA / FXRD-1012NB FXRD-1012NAW / FXRD-1012NBW |
Scintillator | CsI / Gadox |
Pixel Pitch | 124 ㎛ |
Pixel Matrix | 2048 x 2560 pixels |
Image Size | 10" x 12" (25.4 ㎝ x 31.7 ㎝) |
Grayscale | 16 bits |
Image Acquisition Time | Wired : 1.5 s Wireless: 3 s |
Dimensions | 28.7 ㎝ x 35.0 ㎝ x 1.5 ㎝ |
Weight | Wired : 2.0 kg Wireless: 2.2 kg(including battery) |
Battery | Litdium Ion 3100 mAh 3 h(capturing) |
Technology | a-Si TFT |
Spatial Resolution | 4.0 lp/㎜ |
Recommended Cycle Time | 15 s |
Data Interface | Gigabit Etdernet IEEE 802.11n |
X-ray Generator Interface | DR Trigger Mode / AED Mode |
Dust and Water Resistant | IP53 |
X-ray Voltage Range | 40 - 150 kVp |
Operating Environment | 10℃ to 35℃ 30 % to 85 % RH(non-condensing) |
Power Consumption | DC 24 V, 0.8 A |
* Specifications are subject to change witdout prior notice.

CuattroDR offers the simple, beautiful, modern experience that healthcare providers and patients deserve, in an easy to use, easy to deploy form factor. Each CuattroDR configuration is designed to be simple, flexible, and elegant, while providing the best value in total cost of ownership over many years. Whether the need is to upgrade a busy orthopedic suite, or an urgent care imaging suite, a CuattroDR configuration is available, quickly and reliably. CuattroDR is better and affordable... without compromise or worrisome down-time.
